PRODUCT NAME :
carbon tool steel
STANDARD:
GB/T1298-1986 ISO4957
GRADE COMPARISION:
|
GB |
ASTM |
BS |
JIS |
DIN |
|
T10 |
T72301 |
1407 |
SK3 |
C105W1 |
ULTRASONIC STANDARD:
GB/T6402-2008 / SEP921-84. ASTM A388
CHEMICAL COMPOSITION:
|
C |
Si |
Mn |
P≤ |
S≤ |
|
0.95/1.04 |
≤0.35 |
≤0.40 |
0.035 |
0.03 |
HEAT TREATMENT SPECIFICATION:
Temperature for specimen quenching ℃: 760～780
Cooling medium for specimen quenching : water
Specimen quenching hardness ＞HRC: 62
MECHANICAL PROPERTIES:
Hardness HBS: ≤197
Impression diameter mm: ≥4.3
DELIVERY CONDITION :
annealed
DIMENSION : mm
|
ROUND STEEL BAR |
COIL ROD |
WIRE |
SQUARE/ FLAT |
|
FORGED BAR |
ROLLED BAR |
HOT ROLLED |
COLD DRAW |
FORGED |
ROLLED |
|
100-700 |
16-250 |
∮5.5-20 |
∮0.2-13 |
120-800×120-800 |
5-38×44-150 10-90×60-305 |
APPLIED RANGE:
REMARK：
Above listed parameters and sepcification only for reference . Specific parameters according to standard. Requirments beyond
standard will be negotiate by both sides .
Delivery state:annealed, spheroidal annealed, quenched & tempered ,bright bar, cold-drawn, etc.
Listed specifications are only typical grades; products of required specifications can be developed/produced per international,
Chinese or industry standards, or based on agreements with customers.
