PRODUCT NAME :
alloy structure steel
STANDARD:
GB/T3077-1999 EN10083-1 EN10083-3 ISO 683-1
GRADE COMPARISION:
|
GB |
ГОСТ |
ASTM |
BS |
JIS |
NF |
DIN |
|
35Mn2 |
35Г2 |
1335 |
150M36 |
SMn438(H) |
35M5 |
36Mn5 |
ULTRASONIC STANDARD:
GB/T6402-2008 / SEP921-84. ASTM A388
CHEMICAL COMPOSITION:
|
C |
Si |
Mn |
P |
S |
|
0.32-0.39 |
0.17-0.37 |
1.40-1.80 |
≤0.035 |
≤0.035 |
HEAT TREATMENT SPECIFICATION & MECHANICAL PROPERTIES:
Quenching temperature （℃）：840；
Yeild strength （σs/MPa）：≥685tem
Elongation （δ5/%）：≥12
Reduction area （ψ/%）：≥45
Impact （Aku2/J）：≥55
DELIVERY CONDITION :
normalized ,annealed, black surface ,rough machined or quenched & tempered , should be indicated in contract .
DIMENSION : mm
|
ROUND STEEL BAR |
COIL ROD |
WIRE |
SQUARE/ FLAT |
|
FORGED BAR |
ROLLED BAR |
HOT ROLLED |
COLD DRAW |
FORGED |
ROLLED |
|
80-650 |
16-250 |
∮5.5-20 |
∮0.2-13 |
120-800×120-800 |
5-38×44-150 10-90×60-305 |
length : forged bar free length 4-5.8M,rolled bar 5.8M. for customers special requirment, the bar length can do 20 meters long.
APPLIED RANGE:
Ordinary used in quenched and normalized status . In heavy duty ,and middle sized machinery used as connecting rod , mandreal , axle shaft .
REMARK：
Above listed parameters and sepcification only for reference . Specific parameters according to standard. Requirments beyond standard will
be negotiated by both sides.
Delivery state:annealed, spheroidal annealed, quenched & tempered ,bright bar, cold-drawn, etc.
Listed specifications are only typical grades; products of required specifications can be developed/produced as per international, Chinese or i
ndustry standards,orbased on agreements with customers.
